Trek Supercal SL 9.6 Gen 2

Description

Supercaliber SL 9.6 is a carbon cross country mountain bike built for rocketing over singletrack and scorching the way to the finish line. It’s built with a carbon frame that balances stiffness with compliance for power when you need it most, while IsoStrut rear suspension gives you just enough squish to soften the blow through the rough terrain peppering modern XC courses. It comes ready to rip with a 12-speed SRAM Eagle transmission, so you’ve got a gear for every climb and breakaway.

Specs:

Frameset

Frame: SL OCLV Mountain Carbon, IsoStrut, UDH, 80mm travel

Fork: RockShox Reba RL, DebonAir, Motion Control damper, lockout, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 110mm travel

Shock: Trek IsoStrut, RockShox SIDLuxe, 2-position remote damper

Bontrager Drop Lock remote

Wheels

Front wheel: Bontrager Kovee Comp 25, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29”

Rear wheel: Bontrager Kovee Comp 25, Tubeless Ready, Rapid Drive 108, Boost148, 12mm thru axle, 29”

Rear Skewer: Bontrager Switch thru axle, removable lever

Rim strip: Bontrager TLR

Tire: Maxxis Rekon Race, tubeless ready, EXO casing, folding bead, 60tpi, 29×2.40”

Max Tire Size: Frame: 29×2.40″, Fork: See manufacturer

Drivetrain

Shifter: SRAM Eagle 70, 12 speed

Rear derailleur: SRAM Eagle 70, T-Type

Crank:

• Size: S, M, ML: Sram Eagle 70, T-Type, DUB, 32T, 55mm chainline, 170mm length
• Size: L, XL: Sram Eagle 70, T-Type, DUB, 32T, 55mm chainline, 175mm length

Bottom bracket: SRAM DUB, 92mm, PressFit

Cassette: SRAM Eagle XS-1270, T-Type,10-52, 12 speed

Max Chainring Size: 1x: 38T, min 30T

Components

Saddle: Verse Short Comp, steel rails, 145mm width

Seatpost:

• Size S: Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6mm, 310mm length
• Size M, ML, L: Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6mm, 410mm length
• Size XL: Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 31.6mm, 450mm length

Handlebar:

• Size S: Bontrager Comp, alloy, 31.8mm, 5mm rise, 720mm width
• Size M, ML, L, XL: Bontrager Rhythm Comp, alloy, 31.8mm, 15mm rise, 750mm width

Grips: Trek Line Comp, nylon lock-on

Stem:

• Size S: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length
• Size M, ML: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length
• Size L: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 70mm length
• Size XL: Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 80mm length

Headset: FSA IS-2, 1-1/8” top, 1.5” bottom

Brake: SRAM DB 6 4-piston hydraulic disc

Brake Rotor: SRAM CenterLine, 6-bolt, round edge

Rotor Size: Max brake rotor sizes – Frame: 160mm

Weight

M – 12.93 kg / 28.51 lbs (with TLR sealant, no tubes)

This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
